Oval gear flow meter is one of positive displacement flow meter and is mainly composed of meter shell, oval gear rotor and converter. It is an instrument used for continuous or discontinuous metering and control of liquids in the pipeline. It has advantages of large metering range, excellent accuracy, small pressure loss and high viscosity adaptability etc; It has good performance on measuring high-temperature and high viscosity liquids. It is applicable to the calibration and metering of crude oil, chemical, chemical fiber, traffic, commerce, food, medicine and health, scientific research and military etc.

Working Principle And Structure:

Flow meter is installed in the metering tank and the measurement of a pair of oval box gear, with the upper and lower cover an early Lunar sealed cavity (due to rotation of the gear, so sealing is not an absolute) as a unit of emissions. When measured by the pipe into the liquid flow meter, due to pressure generated by the Import and Export Department to promote a pair of differential gears for rotation, the constant measurement by cavity after the beginning of the Lunar liquid delivery to the exit, elliptical gear with each revolution time displacement is the product of four times the measured volume of liquid flow.

SPECIFICATION:
Type: Oval Gear
Size: (DN 8 ~ DN200) mm
Max. Temperature: 20 °C~+250 °C
Max. Pressure: 1.6 Mpa (16 bar)
Accuracy: ±0.2% ±0.5%
Sensor Material: Cast Iron Cast Steel Stainless Steel
Signal Output: Pulse DC4 -20mA, RS 485
Power Supply: 24V DC

Brand: Smart Measurement Co, Ltd, TECHANGE
Origin: USA, China.
